JL Audio JX400/4D 4 Ch. Class D Full-Range Amplifier 400 W

The JX400/4D employs a highly-efficient Class D design with a robust MOSFET power supply to deliver a strong 100 watts to each of its four channels into 2 ohms (14.4V, 1% THD). Use the JX400/4D in combination with our JX500/1D or JX1000/1D monoblocks to build an amazing amplification system at a very affordable price. Or, use the JX400/4D by itself to power two satellites, plus a subwoofer. The JX400/4D includes a defeatable 12 dB / octave filter for each channel bank, which can be configured as a low-pass or high-pass filter and offers continuously variable cutoff frequency selection from 50-200 Hz. Dedicated hi-level inputs are included, in addition to conventional low-level RCA inputs, making it easy to integrate with a variety of OEM and aftermarket head units. Rated Continuous (RMS) Power @ 14.4 V @ 4 Ω 70 W RMS x 4 @ 2 Ω 100 W RMS x 4 Bridged @ 4Ω 200 W RMS x 2 Rated Continuous (RMS) Power @ 12.5 V @ 4 Ω 50 W RMS x 4 @ 2 Ω 80 W RMS x 4 Bridged @ 4Ω 160 W RMS x 2 General Specifications Frequency Response 20 Hz - 20 kHz (+0, -1dB) S/N Ratio, referred to highest rated power >93 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth) S/N Ratio, referred to 1 W >76 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth) Damping Factor @ 4 Ω >60 / 50 Hz Damping Factor @ 2 Ω >30 / 50 Hz THD+N @ Rated Power <1% @ 2 Ω per Ch. Input Voltage Range @ RCA Inputs 200 mV - 4 V RMS Input Voltage Range @ High-Level Inputs 2 V - 10 V RMS Min.Copper Power / Ground Wire Gauge 4 AWG wire Fuse Rating 40 A (AFS, AGU or MaxiFuse™) Signal Processing Filter Mode(s) Low-Pass or High-Pass Filter Slope(s) 12 dB/octave Filter Frequency Range 50 Hz - 200 Hz Detented, Calibrated Filter Freq. Potentiometers No Filter Defeat Function Yes Remote Level Control No Remote Level Modes N/A Channel Input Mode Switch Yes (2/4 ch.) Pass-Through Preamp Output Unbuffered Source Channel Selection for PreOuts No (always 2 Ch) Physical Specifications Height (H) 2.15 in / 55 mm Width (W) 9.05 in / 230 mm Depth (D) 7.68 in / 195 mm Net Weight 4.80 lb / 2.18 kg
